Tilt Legs Adjustable Solar Mounting System For Flat Tin Roof
Solution
Tunxin Aluminum is specialized in marketing and producing various of aluminum profiles since the establishment in 2003.
Based on the experience of aluminum profiles, we developed
different series of solar mounting system.
Product Details
The Tunxin Tilt Legs are designed for the harshest environments on
flat roofs or on the ground. The system is quick and easy to
install, and allows solar panels to be installed in the angle
ranges 10 to 15 degrees, 15 to 30 degrees and 30 to 60 degrees. To
simplify connection of support rails to tilt legs, The Tunxin rails
are designed to allow standard T bolts to be simply swiveled into
the rails.
Specifications
| Installation Site | Low profile Roof or flat roof |
| Tilt Angle | 10-60 degree |
| Building Height | 20 m |
| Wind Load | Up to 60 m/s |
| Snow Load | 70 cm |
| Applicable Module | Framed or frameless |
| Standard | AS/NZS 1170,MCS012, TUV |
| Material | High Class Aluminum alloy Al6005-T5& Stainless steel 304 |
| Color | Natural or Customized |
| Warranty | Ten years warranty and twenty five years service life |
Key Benefits
1.Easy to install:
The tilt-in module can be put into the extruded rail from the any
location and can be high pre-assembly with the clamp and we use
standard T bolts being attached to roof hook to minimize the time
and cost of installation.
2.Offer unmatched durability:
With all structural components comprised of high class stainless
steel and anodized aluminum alloy, it is designed for twenty years
service life and backed by ten years warranty.
3.Stand up to extreme weather:
Tunxin pitched roof racking system is designed to stand up to the
extreme weather complied with the AS/NZ 1170 and other
international structure load standard by the skilled engineer. The
main support components also have been test to guaranty its
structure and load-carrying capacity.
4.Provide broad installation flexibility:
These systems accommodate most commercially available framed solar
panels and diverse roof types, and they can scale easily from small
to large, multi-megawatt installations.
Installation
1. In accordance with the planned array layout, place the
adjustable front support feet and legs in position using the EPDM
waterproof gaskets in between the foot and the roof material. Screw
each foot through the roofing material into the purlins using the
supplied wood screws taking care to place all feet in a straight
line.
2. Use the T-bolts to attach the rail to the adjustable front
support leg. Tighten the M8 hexagon screw securely.
3. Also In accordance with the planned array layout, place the
adjustable rear support feet and legs in position using the EPDM
waterproof gaskets between the foot and the roof material.Screw
each foot through the roofing material into the purlins using the
supplied wood screws taking care to place all feet in a straight
line and in a matching position to the front support feet and legs.
4. Adjust the size of rear leg assembly by extending the central
angle bar to the desired length. Use the supplied fixing nuts to
secure the two sections in place. This method is superior to using
traditional lock screw methods and increases the rear leg’s loading
capacity. Refer to the illustration below:
5. Use the T-bolt to attach the rail to the adjustable rear support
leg.
6. Place solar panels on the rails.
7. Use end clamps with M8*25 Hexagon screw and fixing nuts to
attach solar panels to the rails. Adjacent solar panels are
attached by using mid clamps with M8 Hexagon screws. (The hexagon
screw length is determined by the solar panel’s thickness)
8. Repeat steps until installation is completed.
Packaging
Advantages Of Aluminum Mounting Structure
A.Affordable price :with reasonable design,price of aluminum
mounting system will not be very higher than C-steel mounting
system (only about 25% price difference).
B.Save installation time and labor cost:Aluminum mounting structure
has higher machining accuracy,much lighter weight,and part
pre-assembly in factory,(save 30% installation time)
C.Save maintenance cost:with better anti-corrosion,aluminum
mounting structure will have about 25 years duration
lifetime,almost no need maintenance cost.But C-steel mounting will
have to be repainted and re-welded to keep its service life.
D.High priced recycling:scrap aluminum can be sold in high price
after using (about 40% purchase price of aluminum mounting),while
C-steel will be valueless for years severe corroded.
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: 5-25 after you confirm all details.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample.
Q: What is your terms of payment ?
A: 30% T/T in advance ,balance before shipment.
If you have another question, pls feel free to contact us.
